Product Name:
Auto Paper Feeder Machine
 |
Table 1 Feeder machine main technical parameters
| Max. paper size | 460*600mm |
| Min. paper size | 210*150mm |
| Paper madel | 90~500g |
| Feeder paper speed | 0-65Pc/min |
| Place paper high | 520mm |
| Power | 1kw |
| voltage | 220v/50Hz |
| net weight | 170kg |
| Machine size | 1200*780*1000mm |
| package size | 1370*815*1040mm |
1.Vacuum suction feed mode, and Lamination machine, Labeling Machine and other supporting linkage: save labor and improve efficiency.
2.Can choose intermittent or Continuous feed, Other models can be customized
3.Paper automatically rise, the maximum paper thickness of 45CM.
4.Paper platen lift safety limit function, optional paperless alarm system.
5.Height-adjustable paper Spit position, to solve the gap between the equipment.
Please click the link to see product video:
http://www.gdduoli.com/e_v_show/?id=31
